Double Rod Cylinder

Number

Name

Number

Name

1

Fixing plate

8

Front cover

2

Piston rod

9

Anti-collision washer

3

Anti-collision head

10

Piston seal

4

Cylinder body

11

Piston

5

Circlips for holes

12

Magnet

6

Shaft seal

13

Anti-friction ring

7

O ring

14

Back cover

Bore (mm)

10

16

20

25

32

Working Medium

Air

Operation

Double Acting

Operation Pressure Range

0.1~0.9 MPa

Ensure Pressure Resistance

1.35 MPa

Operation Temperature Range

0~70 ℃

Operation Speed Range

100~500 mm/s

Adjustable Stroke

-10~0 mm

Cushion

Not Available

Cushion Gasket

Pres ion Of Non-rotating

0.4°

0.3°

Port Size

M5 x 0.8

PT 1/8"

Bore (mm)

Standard Stroke

Max. Stroke

Allowable Stroke

10

10 20 30 40 50 60 70

70

100

16

10 20 30 40 50 60 70 80 90 100 125 150

150

200

20

10 20 30 40 50 60 70 80 90 100 125 150

150

200

25

10 20 30 40 50 60 70 80 90 100 125 150

150

200

32

10 20 30 40 50 60 70 80 90 100 125 150

150

200

Bore/Symbol

PA

PB

PC

PD

PE

PF

PG

PH

10

18

0.5

Φ6.2 deep 3.5 mm, Through Hole: Φ4.5

1 5.2

6

3

5.2

M3 × 0.5 deep 5 mm

16

24

1

Φ7.8 deep 4.6 mm, Through Hole: Φ4.5

6.2

8

3

6.2

M4 × 0.7 deep 46 mm

20

28

1

Φ11 deep 6.8 mm, Through Hole: Φ4.5

8.2

10

3

8.2

M6 × 1 deep 48 mm

25

34

1

Φ11 deep 6.8 mm, Through Hole: Φ4.5

10.2

12

3

10.2

M6 × 1 deep 48 mm

32

42

2

Φ17 deep 12 mm, Through Hole: Φ4.5

1 14 1

16

3

1 14

M10 × 1.5 deep 14 mm

Inner Diameter Quantity

Front cover seal

Piston O-ring

Rear cover O-ring

Piston rod O-ring

1

2

2

1

10

PDU-6

APA-10

10×1.5

P12

16

PDU-8

APA-16

16×1.5

P16

20

PDU-10

APA-20

20×1.5

P20

25

PDU-12

APA-25

25×1.5

P20

32

PDU-16

APA-32

32×1.5

P25

Bore Symbol

D

E

I

10

20

30

40

50

60

70

80

90

100

125

150

16

68

15

53

20

30

35

40

45

50

55

60

65

70

75

87 5

100

8

47

6

24

20

78

20

58

20

35

35

40

45

50

55

60

65

70

75

87 5

100

10

55

9

28

25

81

19

62

30

40

40

45

50

55

60

65

70

75

80

92.5

105

10

66

8

34

Bore Symbol

J

K

L

M

N1

N2

P1

P2

Q

R

S

T

V

W

16

M4×0.7 deep 5

47

53

20

22

10

Double side: Φ7.5 Deep: 7.2mm, Through Hole: Φ4.5

Double side: Φ8 Deep: 4.4mm, Through Hole: Φ4.5

34

3

54

21

8

6.2

20

M4×0.7 deep 5

55

61

24

25

12

Double side: Φ7.5 Deep: 7.2mm, Through Hole: Φ4.5

Double side: Φ8 Deep: 4.4mm, Through Hole: Φ4.5

44

3.5

62

25

10

8.1

25

M4×0.8 deep 6

66

72

27

30

12

Double side: Φ7.5 Deep: 7.2mm, Through Hole: Φ4.5

Double side: Φ8 Deep: 4.4mm, Through Hole: Φ4.5

56

7

73

30

12

10.2

Bore Symbol

E

10

20

30

40

50

60

70

10

63

12

51

10

30

30

35

40

45

50

55

32

108

30

78

35

10

20

30

40

50

60

70

80

90

100

125

150

45

50

55

60

65

70

75

80

85

90

102.5

115
