What are the characteristics of solenoid valves?

Main feature

1. External leakage is blocked, internal leakage is easy to control, safe to use
Internal and external leakage is an element that endangers safety. Other automatic control valves usually extend the valve stem, and the rotation or movement of the valve core is controlled by an electric, pneumatic, or hydraulic actuator. This must solve the problem of external leakage of the dynamic seal of the long-term valve stem; only the solenoid valve is completed by using electromagnetic force to act on the iron core sealed in the magnetic isolation sleeve of the electric control valve. There is no dynamic seal, so the external leakage is easy to block. . The torque control of the electric valve is not easy, and it is easy to produce internal leakage, or even pull off the head of the valve stem; the structure of the solenoid valve is easy to control internal leakage until it drops to zero. Therefore, the solenoid valve is particularly safe to use, especially suitable for corrosive, toxic or high and low temperature media.

2. The system is simple, just connect to the computer, the price is low
The solenoid valve itself has a simple structure and low price, and is easier to install and maintain than other types of actuators such as control valves. What's more obvious is that the composed automatic control system is much simpler and the price is much lower. Since the solenoid valve is controlled by a switch signal, it is very convenient to connect with an industrial computer. In today's era when computers are popular and prices drop sharply, the advantages of solenoid valves are even more obvious.

3. Express action, small power, light appearance
The response time of the solenoid valve can be as short as several milliseconds, and even the pilot solenoid valve can be controlled within tens of milliseconds. Since it is a self-contained circuit, it is more sensitive than other automatic control valves. A properly designed solenoid valve coil has very low power consumption and is an energy-saving product; it can also be able to automatically maintain the valve position only by triggering the action, and it does not consume electricity at all. The solenoid valve is small in size, which saves space and is light and beautiful.

4. The adjustment accuracy is limited and the applicable medium is limited
Solenoid valves usually have only two states on and off, and the spool can only be in two extreme positions and cannot be adjusted continuously, so the adjustment accuracy is still subject to certain restrictions.
Solenoid valves have higher requirements for the cleanliness of the medium, and the granular medium cannot be used. If it is impurities, it must be filtered out first. In addition, viscous media cannot be applied, and the viscosity range of the media for specific products is relatively narrow.

5. Diverse models and wide applications
Although solenoid valves have inherent shortcomings, their advantages are still outstanding, so they are designed into a variety of products to meet various needs and have a wide range of uses. The advancement of solenoid valve technology also revolves around how to overcome congenital shortcomings and how to make better use of inherent advantages.
